Vacon 100 Applications Manual

5.4 GROUP 3.4: RAMPS AND BRAKES SETUP
Table 45: Ramp 1 setup
Index Parameter Min Max Unit Default ID Description
P3.4.1.1
Ramp 1 Shape 0.0 100.0 % 0.0 500
You can make
smoother the start and
the end of the
acceleration and
deceleration ramps.
P3.4.1.2 Acceleration Time 1 0.1 300.0 s 5.0 103
Gives the time that is
necessary for the
output frequency to
increase from zero
frequency to maximum
frequency.
P3.4.1.3 Deceleration Time 1 0.1 300.0 s 5.0 104
Gives the time that is
necessary for the
output frequency to
decrease from
maximum frequency to
zero frequency.
