Vacon 100 Applications Manual

Table 44: Jogging parameters
Index Parameter Min Max Unit Default ID Description
P3.3.6.1
Enable DI Jogging Varies Varies
DigIN
Slot0.1
532
Enables the Jogging
function from digital
inputs. Does not have
an effect on the jogging
from the fieldbus. It is
possible to enable
Jogging only when the
drive is in STOP state.
P3.3.6.2
Jogging Reference 1
Activation
Varies Varies
DigIN
Slot0.1
530
Connect to a digital
input to activate
P3.3.6.4. If the input is
activated, the drive
starts.
P3.3.6.3
Jogging Reference 2
Activation
Varies Varies
DigIN
Slot0.1
531
Connect to a digital
input to activate
P3.3.6.5. If the input is
activated, the drive
starts.
P3.3.6.4
Jogging Reference 1 -MaxRef MaxRef Hz 0.00 1239
Gives the frequency
reference when
Jogging Reference 1 is
activated.
P3.3.6.5
Jogging Reference 2 -MaxRef MaxRef Hz 0.00 1240
Gives the frequency
reference when
Jogging Reference 2 is
activated.
P3.3.6.6 Jogging Ramp 0.1 300.0 s 10.0 1257
Gives the acceleration
and deceleration times
when the Jogging
function is active.
* = The selection of the application with parameter P1.2 Application gives the default value.
See the default values in Chapter 11 Appendix 1.
PARAMETERS MENU VACON · 133
24-HOUR SUPPORT +358 (0)201 212 575 · EMAIL: VACON@VACON.COM
