Vacon 100 Applications Manual

1
Language selection (P6.1) The selection is different in all the language
packages
2
Daylight saving* (P5.5.5)
Russia
US
EU
OFF
3 Time* (P5.5.2) hh:mm:ss
4 Year* (P5.5.4) yyyy
5 Date* (P5.5.3) dd.mm.
* If a battery is installed, you see these questions.
6
Run Startup wizard?
Yes
No
To set the parameter values manually, make the selection No and push the OK button.
7
Make a selection of an application (P1.2 Application,
ID212)
Standard
Local/Remote
Multi-step speed
PID control
Multi-purpose
Motor potentiometer
8
Set a value for P3.1.2.2 Motor Type (so that it agrees
with the nameplate)
PM motor
Induction motor
9
Set a value for P3.1.1.1 Motor Nominal Voltage (so
that it agrees with the nameplate)
Range: Varies
10
Set a value for P3.1.1.2 Motor Nominal Frequency
(so that it agrees with the nameplate)
Range: 8.00...320.00 Hz
11
Set a value for P3.1.1.3 Motor Nominal Speed (so
that it agrees with the nameplate)
Range: 24...19200
12 Set a value for P3.1.1.4 Motor Nominal Current Range: Varies
13 Set a value for P3.1.1.5 Motor Cos Phi Range: 0.30-1.00
If you set Motor Type to Induction Motor, you see the next question. If your selection is PM
Motor, the value of parameter P3.1.1.5 Motor Cos Phi is set to 1.00 and the wizard goes
directly to question 14.
QUICK STARTUP GUIDE VACON · 13
24-HOUR SUPPORT +358 (0)201 212 575 · EMAIL: VACON@VACON.COM
1

Vacon 100 Specifications

General

Product type	AC Drive
Enclosure class	IP20
EMC filter	Built-in
Power	0.25 kW - 5.5 kW
Cooling method	Fan
Braking chopper	Optional
