When you activate the Fire mode function, an alarm shows on the display.
CAUTION!
The warranty is void if the Fire mode function is activated! You can use Test mode
to test the Fire mode function and the warranty stays valid.
P3.17.1 FIRE MODE PASSWORD (ID 1599)
Use this parameter to make a selection of the mode of the Fire mode function.
Selection
number
Selection name Description
1002 Enabled mode
The drive resets all the faults and continues to operate at the
same speed until it is not possible
1234 Test mode
The drive does not automatically reset the faults, and the
drive stops when a fault occurs.
P3.17.3 FIRE MODE FREQUENCY (ID 1598)
With this parameter, you can set the frequency reference that is used when Fire mode is
active. The drive uses this frequency when the value of parameter P3.17.2 Fire Mode
Frequency Source is Fire Mode Frequency.
P3.17.4 FIRE MODE ACTIVATION ON OPEN (ID 1596)
If this digital input signal is activated, an alarm shows on the display, and the warranty
becomes void. The type of this digital input signal is NC (normally closed).
It is possible to try the Fire mode with the password that activates the Test mode. Then the
warranty stays valid.
NOTE!
If Fire mode is enabled, and you give the correct password to the parameter Fire
Mode Password, all the Fire mode parameters become locked. To change the Fire
mode parameters, change the value of P3.17.1 Fire Mode Password to 0 first.
VACON · 306 PARAMETER DESCRIPTIONS
