Chapter 8 System Options Alpha Compact 32708612
Version: 14.12.2012 page 100 of 135
015 APPLIC-TRIGGER : 000
Herewith the trigger signal for the extension of the applicator is parameterized. Af-
ter the label was detected at the stamps, the date is in the labeling cycle at which
the trigger is expected.
Push [Enter] to edit the configuration parameter (in case of password query see
page 91).
Push the *buttons [] or [] to increase or reduce the parameter value
(valid range: 000-032).
Push [Enter] to save the value.
Push the buttons [] or [] to get to the next configuration parameter.
Push [Start] or [Stop] to leave the parameter setting.
*Fast forward-function when pushing the button [] or [].
Parame-
ter Value
Connection Function
00
Immediate extension of applicator.
01
Product Sensor 1 (J14)
Edge triggering (rising edge):
Triggering in case of a rising edge, means
the change from "low" to "high". Only in case
of indication "Expect. Trig." A trigger is ac-
cepted. Outside this phase all triggers are
ignored.
02
Product Sensor 2 (J9)
03
Aux.-input at I/O-interface: J16
04
Applicator J3
05
Product Sensor 1 (J14)
Level triggering (rising edge):
Triggering in case of "high"-signal. Repeti-
tion of applying cycle as long as signal is
active (high).
29 - 32
No acceptable parameters.
CONFIGURATION 015
APPLIK. TRIGGER 000
