Chapter 3 Technical Specifications Alpha Compact 32708612
Version: 14.12.2012 page 24 of 135
3. Technical Specifications
Dimensions Labeler
(H x W x D in mm)
715 x 310 x 590 (dependent on applicator version)
Weight
approx. 22 kg (without label roll)
Power Connection:
100-240V / 47-63Hz (1~) with protective conductor
Power Consumption:
*“200 W or *² 300°W see type label
Environmental Tempera-
ture:
10-38 °C
Environmental Conditions:
20-90 % relative air humidity (non-condensing)
Protection Rating:
IP 20
*² Air Pressure Connec-
tion:
5 – 6 bar (according to DIN ISO 8573-1)
Air Pressure quality according to DIN EN ISO 8573-1
- Residual Oil Content (Quality Class 5) = 25 mg/m³
- Residual Dust (Quality Class 3) = 5 µm ; 5 mg/m³
- Residual Water (Quality class 4)= 6 g/m³ ;+3 C
Maximum Air Pressure
Consumption
Up to 200 l/min (under extreme conditions)
(0,3 – 3 Liter per applying cycle)
The system needs a noise pulses-free power supply voltage as usual for systems of DP-
category. Please pay attention to the recommended quality of power supply voltage. (Ask
for Brochure: Preparations for installation of an electronic print and apply system of
Weber Marking Systems).
*² Only if labeler has the appropriate feature.
Information on Further Dimensions:
Minimum Label Width
10 mm
Maximum Label Width
Depending on version either 120 mm or 150 mm
Minimum Label Length
20 mm
Maximum Label Length
300 mm
Applying Distance (for
Tamp-Blow, Blow-Tamp-
On )
0-20 mm distance between product and tamp. Dependent on
application accuracy and label size.
Label Roll, Outside Diame-
ter:
Ø =300 mm (corresponds to ca. 450 running meters) core =
76 mm (3 “), outside winding preferred.
