Chapter 8 System Options Alpha Compact 32708612
Version: 14.12.2012 page 95 of 135
006 LABELS BURST (LABELS BURST)
Herewith the number of label application per start signal (trigger signal) is adjusted. If the
parameter is set on 000, 1 label per start signal will be applied.
Push [Enter] to edit the configuration parameter (in case of password query see
page 91).
Push the *buttons [] or [] to increase or reduce the value.
Push [Enter] to confirm the entry.
Push [Start] or [Stop] to leave the parameter setting.
007 LABEL TRIGGER (LABEL TRIGGER)
Herewith it is determined which sensor input and what kind of signal generates the start
signal for labeling. The functions are combined with each other with the help of arithmetic
sum or are activated separately.
Push [Enter] to edit the configuration parameter (in case of password query see
page 91).
Push the *buttons [] or [] to increase or reduce the value.
Push [Enter] to confirm the entry.
Push [Start] or [Stop] to leave the parameter setting.
Parameter Function
000
As soon as the labeler is ready, the application starts.
001
The first (primary) product sensor input is selected as start sensor.
002
The second (secondary) product sensor input is selected as start sensor.
+4 As start signal not a switching edge is used but an input level.
As long as an input level is available, the application cycle is repeated.
This enables e. g. the multiple labeling of products with different lengths.
+8 A start signal is only accepted after terminated labeling applying cycle for an again
label application. If the label applying cycle is not yet terminated, an early start
signal leads to error message E07. This function cannot be combined with param-
eter +004.
+16 Selects leading edge as starting signal.
+32 Enables the connection of a NPN sensor as start signal-sensors. (Standard is a
PNP sensor).
CONFIGURATION 006
LABELS BURST 001
CONFIGURATION 007
LABEL TRIGGER 001
