Weber ALPHA COMPACT User Manual

Chapter 4 Description of the Labeler Alpha Compact 32708612
Version: 14.12.2012 page 28 of 135
Complete Overview of the Alpha Compact
Fig.: 4-3 Alpha Compact Assembly Groups
No. Description
1
CABINET WITH CONTROLLER
2
CONNECTOR
3
*² ON / OFF SWITCH (OPTION)
4
UNWINDER
5
UNWINDER DISC WITH CLAMPING
6
DANCER ARM FOR UNWINDING
7
DANCER ARM FOR REWINDING
8
REWINDER
9
FEEDING UNIT (FRICTION ROLLERS)
10
CLAMPING FLANGE
11
PEELER BAR (PEELER BLADE)
12
LABEL SENSOR
13
CONNECTORS
14
BELT BRAKE
Subdivision of the product range of the Alpha Compact
See chapter [System Options] p.114.
