Chapter 8 System Options Alpha Compact 32708612
Version: 14.12.2012 page 90 of 135
CONFIGURATION-Menu
The configuration menu can be reached by pushing the buttons [Enter] and [] at the
same time assuming that the labeler is in stand-by.
This menu includes parameter settings for the whole labeler configuration which deter-
mine the sequence of events during an applying cycle.
On page 100 you have the opportunity to enter your parameters in a list.
CONFIGURATIONS-Address
The display shows in the first line behind "CONFIGURATION" a number with 3 digits (e.g.
"001"). Thus the number represents the currently selected address. In line 2 the respec-
tively selected parameter is noted.
PARAMETER IN CONFIGURATIONS-MENU ADDRESS
LABEL LENGTH CM:
001
LABEL POSITION CM:
002
SPEED M/MIN
003
LABEL OPTIONS
004
WAITING QUEUE
005
LABELS PER TRIG.
006
LABEL TRIGGER
007
PROD. DELAY
008
ING. TRIGGER
009
SYNC-PULSE TIME
010
SYNC-PULSE DELAY
011
CALIBRATE LABEL
012
VACUUM LEVEL:
013
VACUUM TIMEOUT:
014
APPLIC-TRIGGER:
015
EXTENSION DELAY
016
EXTENSION TIME
017
PROXIMITY T. OUT
018
BLOW TRIGGER:
019
BLOW DELAY
020
BLOW TIME
021
HOME TIMEOUT:
022
BARCODE READING TIME
023
CYCLE OPTION:
024
CONFIGURATION 001
LABEL LENGTH CM:
