Chapter 8 System Options Alpha Compact 32708612
Version: 14.12.2012 page 96 of 135
008 TRIGGER DELAY (TRIGGER DELAY)
Herewith a delay is adjusted between trigger and label application. The delay can be be-
tween 0 up to app. 255 mm. The length of the pulse corresponding to each entered value
x 1 mm. Because of the acceleration of the motor is a linear adjustment not possible
(hence app. 1mm).This feature can be used to change the label position without mechani-
cal adjustment of the start sensor.
Push [Enter] to edit the configuration parameter (in case of password query see
page 91).
Push the *buttons [] or [] to increase or reduce the value.
Push [Enter] to confirm the entry.
Push [Start] or [Stop] to leave the parameter setting.
009 TRIGGER BLANK
With parameter 009 IGN TRIGGER , a start trigger debouncing can be adjusted, e.g. at
products with foil packaging.
If in parameter „006 LABELS PER TRIG“. More than one label per triggering was select-
ed, with parameter 009 IGN TRIGGER the distance between the single label applications
is adjusted.
If a shaft encoder is connected, the adjustment is arranged in millimeters. If there is no
shaft encoder connected, the adjustment is arranged in milliseconds.
Push [Enter] to edit the configuration parameter (in case of password query see
page 91).
Push the *buttons [] or [] to increase or reduce the value.
Push [Enter] to confirm the input.
Push [Start] or [Stop] to leave the parameter setting.
*Fast forward-function when pushing the button [] or [].
CONFIGURATION 008
TRIGGER DELAY: 001
CONFIGURATION 009
TRIGGER BLANK 000
To Next Page
