Page #103 background imageLoading...
Page #103 background image
Chapter 8 System Options Alpha Compact 32708612
Version: 14.12.2012 page 103 of 135
019 BLOW TRIGGER
Herewith the trigger signal for the blow-off of a label is adjusted. In case of value “000” the
label will be blown off without delay or rather automatically. Higher values stop the apply-
ing cycle at this point and the applicator waits for the pre-defined trigger signal.
Depending on the configuration additionally the trigger can be used for the control of the
external stop function or rather for starting the labeling operation.
If the Alpha Compact operates with a variable stroke, the value has to be “000” according
to factory setting.
Push [Enter] to edit the configuration parameter (in case of password query see
page 91).
Push the *buttons [] or [] to increase or reduce the parameter value.
(valid range: 000-032).
Push [Enter] to save the value.
Push the buttons [] or [] to get to the next configuration parameter.
Push [Start] or [Stop] to leave the parameter setting.
*Fast forward-function when pushing the button [] or [].
Parame-
ter
Value
Connection Function
00
Automatic blow-off of the label.
01
Product Sensor 1 (J14)
Edge triggering (rising edge):
Triggering in case of a rising edge, means
the change from "low" to "high". Only in case
of indication "Expect. Trig." A trigger is ac-
cepted. Outside this phase all triggers are
ignored.
02
Product Sensor 2 (J9)
03
Aux.-input at I/O-interface: J16
04
Applicator J3
05
Product Sensor 1 (J14)
Level triggering (rising edge):
Triggering in case of "high"-signal. Repeti-
tion of applying cycle as long as signal is
active (high).
29 - 32
No acceptable parameters.
CONFIGURATION 019
BLOW TRIGGER 000
