Weber ALPHA COMPACT User Manual

Chapter 3 Technical Specifications Alpha Compact 32708612
Version: 14.12.2012 page 25 of 135
Performance Data
Application Accuracy
(Wipe-On and Tamp-On-
Applicators)
+/- 0,8 mm
Application Rate Wipe-On /
Blow Box
Up to 600 labels per min.
Application Rate Tamp-On
Applicators
Up to120 labels per min.
Application Performance
Max. 50 m per minute
Signal Connections
Start-Connection (Trigger)
Signaltyp: PNP(Hilfsspannung +24 Volt +/- 7 %)
Stop-Light Barrier
Type NPN (forked light barrier)
Information on Operation
Panel Controller
2 rotary and 4 push buttons
Display Controller
Display: LCD with background lighting, 2-lines 16-digit and 5
push buttons
Noise Level
The measuring in a distance of 1 meter to system surface and 1,60 meter above the floor
provided the following noise levels:
(Measuring without optional blowing up-system)
A- Sound Pressure Level
<70 dB (A)
