Chapter 6 Installation and Initial Operation Alpha Compact 32708612
Version: 14.12.2012 page 36 of 135
*² System for fixing at stands of the Bluhm Weber Group!
If the system is fixed at a Stand of the Bluhm Weber Group, you will please follow the in-
stallation instructions.
Requirements
The labeler is completely mounted (in protective cabinet or at stand > s. advice
above).
The labeler is available unpacked and prepared at the installation site (s. chapter
"Transport")
Connections for air pressure and power according to "Technical Data" are in-
stalled close to the labeling site (max. 1,50 m away).
Footprint is fixed, horizontal and flat.
*² Only if system is equipped accordingly.
Required Resources
Screw wrench (for adjustment of rubber feet)
Air lever
Instruction
Please position the labeler as follows
Step Procedure
1
If possible, adjust the labeler at the stand to the lowest position, so the balance
point is very low.
Pay attention to asperities or changing state of floor during transportation. It
might cause an abrupt stop of a roll, so the stand and system could fall.
2
Roll the labeler to the labeling site. Move labelers without rolls to installation site
piece by piece diagonally. Consider all points for "
Placing the Labeler" on page
34.
3
Adjust the labeler with an air lever by the adjustable feet horizontally (if the la-
beler has rollers, please arrest the handbrake).
4
Consider when positioning the labeler that the applicator (extended tamp) may
come close to the product up to 10-50 mm, but is not allowed to touch it.
