Chapter 6
Installation and Initial Operation
Alpha Compact 32708612
Version:
14.12.2012
page 55 of 135
Following graphics shows the correlation between the Start T
rigger Signal and the SYNC-
PULSE TIME depending on parameter setting 010 and 011 in configuration menu (see p.
97).
Start Tigger
(
X2)
1
0
Label feed
1
0
Sync Signal
(X9)
Parameter 10 and 011
Value=000,
1
0
Sync Signal
(X9)
Parameter 10 value
>001 and Parameter
011 value =0
1
0
Sync Signal
(X9)
Parameter 10 value
>001 and Parameter
011 value =>001
1
0
t
54
56
