Weber ALPHA COMPACT User Manual

Chapter 6 Installation and Initial Operation Alpha Compact 32708612
Version: 14.12.2012 page 66 of 135
Fig.: 6-24 Wipe-On-Setting
No. Description
1 PEELER BLADE
2 CLAMPING SCREW
3 PUSHER ROLLER
4 PRODUCT
A DISTANCE TO PEELER BAR
B DISTANCE BETWEEN PUSHER ROLLER AND PRODUCT
A the distance between peeler bar and pusher roller.
B the adjustment of the pusher roller to the product.
Requirements
 Labels are loaded.
 Supply of products is stopped.
 Labeler is adjusted in direction to the product.
 Labeler is separated from supply voltage.
