Western Scale M2000 - M2000 Appendices

87
TECHNICAL MANUAL
5002P
0
63P
P
0
64P
6. Select the current loop mode (Parameter 63).
7. Span the current loop for maximum (20 mA) output at the selected
weight (Parameter 64).
• Enter the desired weight for 20 mA output. It is good practice to
increase this number by one or two grads to keep the output
within metering range.
