WinGD X72 Maintenance Manual

Maintenance
0330−1/A1
Winterthur Gas & Diesel Ltd.
9/ 27
Cylinder Liner
Group
Key No.
Description Measuring
direction
(method of
measuring)
Nominal
dimension
(normal, new)
[mm]
Maximum clearance,
dimension
(due to wear)
[mm]
2130 Water guide jacket on cylinder
cover
Water guide jacket upper part Ø
1010
+ 0.30
+ 0.10
1 Clearance total 0.40−0.80
Water guide jacket upper part Ø
989
+ 0.30
+ 0.10
2 Clearance total 1.40−1.80
Water guide jacket lower part Ø
1016
+ 0.10
− 0.10
3 Clearance total 0.10−0.60
Water guide jacket lower part Ø
962
+ 0.30
+ 0.10
4 Clearance total 0.30−0.70
2124 Cylinder liner
*5 Cylinder liner bore radial 720 725.0
* Pay attention to measuring point!
2015
Clearance Table
