WinGD X72 Maintenance Manual

Maintenance
6420−1/A1
Winterthur Gas & Diesel Ltd.
1/ 4
Clean and do Checks
1. Scavenge Air Receiver − Checks and Cleaning 2......................
2. Flaps 3............................................................
2.1 Removal 3....................................................
2.2 Installation 3.................................................
3. Relief Valve − Check 4..............................................
WCH02238
III
III
I
I
WCH02238
2
II - II
WCH02238
1
III - III
IV
2
II
II
For View IV see Fig. 3
Fig. 1: Scavenge Air Receiver
2015
Scavenge Air Receiver
