Maintenance
8460−1/A1
Winterthur Gas & Diesel Ltd.
1/ 5
Removal, Grind the Sealing Faces and Installation
Tools:
1 Grinding tool 94841
1 Stencil 94841A
1. Preparation 2.......................................................
2. Removal 3.........................................................
3. Sealing Faces − Grind 4.............................................
4. Adjustment 5.......................................................
5. Installation 5.......................................................
4
3
1
II
II
I
I
5
2
WCH022562
Fig. 1
For Views I−I and I−I:
See Fig. 3 and Fig. 4 for Removal
and Fig. 7 for Installation
1 Flange 4 Flange
2 Top housing 5 Hydraulic pipe
3 Exhaust valve control unit (VCU)
Hydraulic Pipe − Exhaust Valve Drive
2015
