WinGD X72 Maintenance Manual

Maintenance9403−3/A1
Winterthur Gas & Diesel Ltd.
2/ 12
2. Overview of Pre-tensioning Jacks
Tool 94110 Thrust Device for Main Bearing Cover
1 Piston 7 Vent screw
2 Back-up ring
O-ring
Sealing ring
8 Adapter piece
3 9 Closing valve
4 Cylinder
5 Back-up ring
O-ring
Sealing ring
6
94110−KJ K
it with back-up and O-rings
for pre-tensioning J
ack
MAX. STROKE
9.5 MM
1
7
4
5
9
8
3
6
2
94110−KJ
WCH02305
Fig. 2
Fig. 3
2015
Hydraulic Pre-tensioning Jacks: Storage, Servicing and Maintenance
