Maintenance0360−1/A1
Winterthur Gas & Diesel Ltd.
2/ 3
Group Component Design kg
3306 Connecting rod shaft 4095
3306 Bearing cover for bottom end
bearing with elastic studs
511−519
3310 Bearing shell for bottom end bearing 60
3312 Bearing cover for top end bearing 671
3315 Bearing shell for top end bearing 101
3326 Crosshead
Crosshead with guide shoes
Guide shoe
2278
3434
535
3403 Piston with piston rod
Piston head
Piston skirt
Piston rod
Spray plate with oil pipe
Piston rings
2635
683
112
1702
102
18
3603 Toggle lever to piston cooling and
crosshead lubrication
105
4
4106 Gear wheel on crankshaft 2-part 2880
4325 Shut-off for starting air 246
5
5591 Servo oil pump 91
5556 Fuel pump 420
5564 Injection control unit 74
5580 Fuel pump unit with pumps, casing,
and camshaft
3 x fuel pumps 4566
5581 Camshaft with gear wheel 3 x fuel pumps ca. 700
5591 Servo pump unit with pumps, gear
wheels
Gear wheel pair
2 x servo oil
pumps
472
14
5612 Exhaust valve control unit 35
2016−11
