Xerox WorkCentre 5022 Service Manual

06/2014
6-3
WC 5022/5024
6.1.1 Product Name/Product Code/Serial No.
General
Version 1.0
6.1.1 Product Name/Product Code/Serial No.
6.1.1.1 Main Unit
6.1.1.2 Options
6.1.2 Configuration
This IOT is a Black & White print engine that uses the electrophotographic method with semi-
conductor laser beam.
The output performance when transporting A4 LEF and 8.5x11" LEF Plain paper is 24 ppm/22
ppm. The resolution of the IOT Engine is 600 dots/25.4 mm.
This IOT forms a Multi-Function System in combination with the System Controller, UI, IIT, and
DADF.
6.1.2.1 IOT Overview
Table 1
Destination Product Name CPM Product Code Serial No. Note
DMO-W WorkCentre 5022 22 G8B G8B267501 ~ G8B292500 USB Print/Scan, DADF, Duplex
DMO-W WorkCentre 5024 24 G7B G7B292501 ~ G7B317500 USB Print/Scan, DADF, Duplex
DMO-E & DMO-W WorkCentre 5022 22 G5B G5B377501 ~ G5B437500
333377501x ~ 333437500x
USB Print/Scan, DADF, Duplex
DMO-E & DMO-W WorkCentre 5024 24 G6B G6B317501 ~ G6B377500
333317501x ~ 333377500x
USB Print/Scan, DADF, Duplex
India Direct WorkCentre 5022 22 G2X 333437501x ~ 333467500x USB Print/Scan, DADF, Duplex
India Direct WorkCentre 5024 24 G9B 333467501x ~ 333497500x USB Print/Scan, DADF, Duplex
Table 2
Option Part No. Remarks
1 Tray Module 497K14780 Tray 2, 500 sheets
2 Tray Module 497K14790 Trays 3 & 4, must have 1 Tray Module
Stand 497K11620 Mobile stand, must have 1 Tray Module
Network Kit 497K14820 Enables Network Scan & Print
Fax Kit 497K14810 Includes Speed Dial Pad
Tray Lock 497K14800 Tray 1 only
Table 1
Item Contents
Recording System Electrophotograhic method using OPC Drum
Photoreceptor Type/Diameter OPC/30 mm in diameter
Development Method (1 component, 2 com-
ponents, etc.)
Dry bicomponent development method
Toner component (crush method, polymer-
ization method)
EA (HG base) Toner/6.5 Micrometer
Exposure System Semiconductor laser scanning method
Transfer Method (charger, etc.) Transfer Roll Method
Fusing System Heat pressure fusing method by Heat Roll
Cleaning Method Drum: Blade method/Transfer Roll: None

Xerox WorkCentre 5022 Specifications

General

Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Connectivity	USB 2.0
Functions	Print, Copy, Scan
Duplex Printing	Manual
Paper Sizes	A3, A4, A5, B4, B5
Memory (Standard)	128 MB
Print Technology	Laser
Print Speed	Up to 22 ppm
Print Resolution	600 x 600 dpi
Copy Speed	Up to 22 cpm
Operating System Compatibility	Windows, Mac
First Page Out Time (Copy)	8 seconds
