Chapter 1: SelectIO Resources
SSTL15_R, SSTL135_R, DIFF_SSTL15_R, DIFF_SSTL135_R
The reduced drive-strength R standards are versions of the standard drivers, which can be
preferred for short, point-to-point board topologies. Parallel end-termination resistors
(commonly 50Ω) to V
TT
=(V
CCO
/2) are typically placed on the board close to any receiver.
The differential (DIFF_) versions use complementary single-ended drivers for outputs and
differential receivers for inputs.
SSTL18_I, DIFF_SSTL18_I
These standards are only available for unidirectional (input or output) signals. Class-I
drivers can be preferred for short, point-to-point board topologies. Parallel
end-termination resistors (commonly 50Ω) to V
TT
=(V
CCO
/2) are typically placed on the
board close to any receiver. The differential (DIFF_) version uses complementary
single-ended drivers for outputs and differential receivers for inputs.
SSTL18_I_DCI, DIFF_SSTL18_I_DCI
These standards are only available for unidirectional (input or output) signals. Class-I
drivers can be preferred for short, point-to-point board topologies. DCI provides tuned
internal parallel split-termination resistors that are always present (for receivers). The
value of both the pull-up and pull-down resistors mirror the resistance measured on the
VRN/VRP pins, creating the Thevenin equivalent resistance to the V
CCO
/2 mid-point
level. The differential (DIFF_) version uses complementary single-ended drivers for
outputs and differential receivers for inputs.
SSTL18_II, SSTL15, SSTL135, DIFF_SSTL18_II, DIFF_SSTL15,
DIFF_SSTL135
Parallel end-termination resistors (commonly 50Ω) to V
TT
=(V
CCO
/2) are typically placed
on the board close to any receiver. The differential (DIFF_) versions use complementary
single-ended drivers for outputs and differential receivers for inputs.
Table 1-30: Available I/O Bank Type
HR HP
Available N/A
Table 1-31: Available I/O Bank Type
HR HP
Available Available
Table 1-32: Available I/O Bank Type
HR HP
N/A Available
Table 1-33: Available I/O Bank Type
HR HP
Available Available
