7 Series FPGAs SelectIO Resources User Guide www.xilinx.com UG471 (v1.10) May 8, 2018
The information disclosed to you hereunder (the "Materials") is provided solely for the selection and use of Xilinx products. To the maximum
extent permitted by applicable law: (1) Materials are made available "AS IS" and with all faults, Xilinx hereby DISCLAIMS ALL
WARRANTIES AND CONDITIONS, EXPRESS, IMPLIED, OR STATUTORY, INCLUDING BUT NOT LIMITED TO WARRANTIES OF
MERCHANTABILITY, NON-INFRINGEMENT, OR FITNESS FOR ANY PARTICULAR PURPOSE; and (2) Xilinx shall not be liable (whether
in contract or tort, including negligence, or under any other theory of liability) for any loss or damage of any kind or nature related to, arising
under, or in connection with, the Materials (including your use of the Materials), including for any direct, indirect, special, incidental, or
consequential loss or damage (including loss of data, profits, goodwill, or any type of loss or damage suffered as a result of any action
brought by a third party) even if such damage or loss was reasonably foreseeable or Xilinx had been advised of the possibility of the same.
Xilinx assumes no obligation to correct any errors contained in the Materials, or to advise you of any corrections or update. You may not
reproduce, modify, distribute, or publicly display the Materials without prior written consent. Certain products are subject to the terms and
conditions of the Limited Warranties which can be viewed at http://www.xilinx.com/warranty.htm
; IP cores may be subject to warranty and
support terms contained in a license issued to you by Xilinx. Xilinx products are not designed or intended to be fail-safe or for use in any
application requiring fail-safe performance; you assume sole risk and liability for use of Xilinx products in Critical Applications:
http://www.xilinx.com/warranty.htm#critapps
.
AUTOMOTIVE APPLICATIONS DISCLAIMER
AUTOMOTIVE PRODUCTS (IDENTIFIED AS “XA” IN THE PART NUMBER) ARE NOT WARRANTED FOR USE IN THE DEPLOYMENT
OF AIRBAGS OR FOR USE IN APPLICATIONS THAT AFFECT CONTROL OF A VEHICLE (“SAFETY APPLICATION”) UNLESS THERE
IS A SAFETY CONCEPT OR REDUNDANCY FEATURE CONSISTENT WITH THE ISO 26262 AUTOMOTIVE SAFETY STANDARD
(“SAFETY DESIGN”). CUSTOMER SHALL, PRIOR TO USING OR DISTRIBUTING ANY SYSTEMS THAT INCORPORATE PRODUCTS,
THOROUGHLY TEST SUCH SYSTEMS FOR SAFETY PURPOSES. USE OF PRODUCTS IN A SAFETY APPLICATION WITHOUT A
SAFETY DESIGN IS FULLY AT THE RISK OF CUSTOMER, SUBJECT ONLY TO APPLICABLE LAWS AND REGULATIONS GOVERNING
LIMITATIONS ON PRODUCT LIABILITY.
© Copyright 2011–2018 Xilinx, Inc. XILINX, the Xilinx logo, Virtex, Zynq, Artix, Kintex, Spartan, ISE and other designated brands included
herein are trademarks of Xilinx in the United States and other countries. All other trademarks are the property of their respective owners.
Revision History
The following table shows the revision history for this document.
Date Version Revision
03/01/2011 1.0 Initial Xilinx release.
04/06/2011 1.0.1 Updated disclaimer and copyright sections on page 2.
05/31/2011 1.1 Added New Features. Updated the example device including Figure 1-15 and the
partgen example on page 24. Added VRN/VRP External Resistance Design Migration
Guidelines.
Updated the BITSLIP Submodule section including Figure 3-12. Removed Figure 3-13:
Bits from Data Input Stream (D) of Figure 3-12.
07/20/2012 1.2 Updated paragraph before Table 1-1. Added LVDS signaling to Table 1-1. Updated
V
CCO
and V
CCAUX_IO
. Updated Xilinx DCI. Removed V
CCINT
. Added Match_cycle
Configuration Option, DCIUpdateMode Configuration Option, DCIRESET Primitive,
and Special DCI Requirements for Some Banks. Updated DCI Cascading. Updated DCI
cascading guidelines after Figure 1-7. Updated table note in Table 1-3. Added
Uncalibrated Split Termination in High-Range I/O Banks (IN_TERM). Updated 7 Series
FPGA SelectIO Primitives. Added DCI_CASCADE Constraint and VCCAUX_IO
Constraint. Updated IBUF_LOW_PWR Attribute, Output Slew Rate Attributes, Output
Drive Strength Attributes, PULLUP/PULLDOWN/KEEPER Attribute for IBUF,
OBUFT, and IOBUF, and 7 Series FPGA I/O Resource VHDL/Verilog Examples. Put
Internal V
REF
inside Differential Termination Attribute, page 49. Updated DRIVE
attribute in Table 1-10. Updated titles of Figure 1-41 through Figure 1-44. Updated LVDS
and LVDS_25 (Low Voltage Differential Signaling), including adding Figure 1-72.
Added IN_TERM attribute to SSTL (Stub-Series Terminated Logic). Added table note to
Table 1-55. Added Simultaneous Switching Outputs.
