7 Series FPGAs SelectIO Resources User Guide www.xilinx.com 23
UG471 (v1.10) May 8, 2018
7 Series FPGA DCI—Only available in the HP I/O banks
Figure 1-7 shows DCI cascading support over multiple I/O banks. Bank B is the master
I/O bank, and Banks A and C are considered slave I/O banks.
X-Ref Target - Figure 1-7
Figure 1-7: DCI Cascading Supported Over Multiple I/O Banks
UG471_c1_09_011811
DCI VRN/VRP
Bank A
Bank B
Bank C
To
Local
Bank
To
Local
Bank
To
Local
Bank
To Banks Above
(When Cascaded)
To Banks Below
(When Cascaded)
