YASKAWA E-S Series - Page 273

11.1 List of Parameters
11.1.2 List of Parameters
11-23
11
Parameter List
PnBCD
2
/TGON
(Rotation
Detection Output)
Signal Allocation
0000h to
00C2h
− 0002h
After
restart
Setup page 5-15
PnBCE
2
/NEAR
(Near Output) Sig-
nal Allocation
0000h to
00C2h
− 0002h
After
restart
Setup page 5-15
PnBCF
2
/V-CMP
(Speed
Coincidence
Detection Output)
Signal Allocation
0000h to
00C2h
− 0002h
After
restart
Setup page 5-16
Continued on next page.
Continued from previous page.
Parameter
No.
Size Name
Setting
Range
Setting
Unit
Default
Setting
When
Enabled
Classi-
fication
Reference
n.X Signal Usage Method
0 Turn ON (close) the output while the Servomotor is rotating.
1 Turn OFF (open) the output while the Servomotor is rotating.
2 Do not use this signal.
n.X Signal Terminal Number
Same as PnBC0 = n.X.
n.X Reserved parameter (Do not change.)
n.X Reserved parameter (Do not change.)
n.X Signal Usage Method
0
Turn ON (close) the output when the position deviation is equal to or greater than
the setting of PnB2F (Near Signal Width).
1
Turn OFF (open) the output when the position deviation is equal to or greater than
the setting of PnB2F (Near Signal Width).
2 Do not use this signal.
n.X Signal Terminal Number
Same as PnBC0 = n.X.
n.X Reserved parameter (Do not change.)
n.X Reserved parameter (Do not change.)
n.X Signal Usage Method
0 Turn ON (close) the output while the speed coincides.
1 Turn OFF (open) the output while the speed coincides.
2 Do not use this signal.
n.X Signal Terminal Number
Same as PnBC0 = n.X.
n.X Reserved parameter (Do not change.)
n.X Reserved parameter (Do not change.)
