4 SERVOPACK Specifications and Dimensional Drawings
4.1.3 Single-phase 220 V (Option)
4-4
4.1.3 Single-phase 220 V (Option)
The value of the input power supply voltage is maximum 253 Vrms.
* When a power supply of 187V (-15% of 220V) or less is used, alarm 41 which indicates voltage short-
age, may occur when accelerating to maximum speed with maximum torque of servomotor.
4.1.4 Three-phase 400 V
The value of the input power supply voltage is maximum 528 Vrms.
SERVOPACK Model SGDH- 08AE-S 15AE-S
Max. Applicable Servomotor
Capacity (kW)
0.75 1.5
Continuous Output Current
(Arms)
5.7 11.6
Max. Output Current (Arms)
13.9 28
Input Power
Supply
Main Circuit
Single-phase/Three-phase 220 to 230 VAC +10 to -15%, 50/60 Hz
∗
Control Circuit Single-phase 220 to 230 VAC +10 to -15%, 50/60 Hz
Configuration Base-mounted (Rack mounting available as an option)
Regenerative Processing Built-in
SERVOPACK Model SGDH- 05D 10D 15D 20D 30D 50D 60D 75D 1AD 1ED
Max. Applicable Servomotor
Capacity (kW)
0.45 1.0 1.5 2.0 3.0 5.0 6.0 7.5 11 15
Continuous Output Current
(Arms)
1.9 3.5 5.4 8.4 11.9 16.5 20.8 25.4 28.1 37.2
Max. Output Current (Arms)
5.5 8.5 14 20 28 40.5 55 65 70 85
Input Power
Supply
Main Circuit Three-phase 380 to 480 VAC +10 to -15%, 50/60 Hz
Control Circuit 24 VDC ±15%
Configuration Base-mounted
(Rack mounting available as an option)
Base-mounted (Duct-venti-
lated available as an option)
Regenerative Processing Built-in External regenerative resistor
To Next Page
