5.2 Servomotor Main Circuit Wire Size and Connectors
5-7
5
5.2 Servomotor Main Circuit Wire Size and Connectors
5.2.1 Wire Size
(1) 100 V, 200 V, and 400 V SGMAH Servomotors
(2) 100 V, 200 V, and 400 V SGMPH Servomotors





 


 "#$
 %&'
&"( ( )(' "#$
Rated Output 30 W to 750 W
Three-phase
100 V
AWG20
Three-phase
200 V
Three-phase
400 V
Rated Output 100 W 200 to 400 W 750 W 1.5 kW
Three-phase
100 V
AWG22 AWG20
AWG16
(HIV 1.25)
Three-phase
200 V
Three-phase
400 V
