YASKAWA SGDH - Selections

2-1
2
2
Selections
2.1 Servomotor Model Designations - - - - - - - - - - - - - - - - - - - - - 2-2
2.1.1 Model SGMAH (3000 min
-1
) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-2
2.1.2 Model SGMPH (3000 min
-1
) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-4
2.1.3 Model SGMGH (1500 min
-1
) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-6
2.1.4 Model SGMGH (1000 min
-1
) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-8
2.1.5 Model SGMSH (3000 min
-1
) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-10
2.1.6 Model SGMDH (2000 min
-1
) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-12
2.1.7 Model SGMUH (6000 min
-1
) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-13
2.2
Selecting Servomotors
- - - - - - - - - - - - - - - - - - - - - - - - - - - 2-14
2.2.1
Support Tool for the Capacity Selection of the AC Servomotors
- - - - 2-14
2.2.2
Servomotor Capacity Selection Examples
- - - - - - - - - - - - - - - - - - - 2-14
2.3 SERVOPACK Model Designations - - - - - - - - - - - - - - - - - - 2-15
2.4 Σ
-
II Series SERVOPACKs and Applicable Servomotors - - - 2-16
2.5 Selecting Cables - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-17
2.5.1 Cables for SGMAH and SGMPH Servomotors - - - - - - - - - - - - - - - - 2-17
2.5.2 Cables for SGMGH/SGMSH/SGMDH/SGMUH Servomotors - - - - - - 2-22
2.6 Selecting Peripheral Devices - - - - - - - - - - - - - - - - - - - - - - 2-26
2.6.1 Special Options - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-26
2.6.2 Molded-case Circuit Breaker and Fuse Capacity - - - - - - - - - - - - - - - 2-29
2.6.3 Noise Filters, Magnetic Contactors, Surge Suppressors
and DC Reactors - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2-30
2.6.4 Regenerative Resistors and Brake Power Supply Units - - - - - - - - - - 2-31
