1.2 Product Part Names
1.2.1 Servomotors
(1) SGMAH and SGMPH Without Gears and Brakes
(2) SGMGH/SGMSH/SGMDH/SGMUH Without Gears and Brakes
Flange
Output
shaft
Nameplate
Encoderconnector
Servomotorconnector
Servomotor
maincircuitcable
Encoder
cable
Encoder
(Detectingsection)
Flange
Nameplate
Encoder
connector
Encoder
(Detectingsection)
Servomotorconnector
Output
shaft
