YASKAWA SGDH - Σ-II Series SERVOPACKs and Applicable Servomotors

2 Selections
2-16
2.4
Σ
-
II Series SERVOPACKs and Applicable Servomotors
Note: 1. =A: 200 V, B: 100 V, D: 400 V (Be sure to match the voltage ratio on the servomotor and the
SERVOPACK.)
2. Servomotors with low-backlash gears are available.
Table 2.1 SERVOPACKs and Applicable Servomotors
Σ
-
II
Series SGM

H Servomotor
Σ
-
II
Series SGDH SERVOPACK
Single-phase
100 VAC
Single-phase
200 VAC
Three-phase
200 VAC
Three-phase
400 VAC
SGMAH
(Super High Power
Capacity)
3000min
-1
8 models
A3

(30 W)
A3BE A3AE −−
A5

(50 W)
A5BE A5AE −
01

(100 W)
01BE 01AE −−
02

(200 W)
02BE 02AE −−
03

(300 W)
−−−05DE
04

(400 W)
− 04AE −−
07

(650 W)
−−−10DE
08

(750 W)
− 08AE-S 08AE −
SGMPH
(Flat Type)
3000min
-1
5 models
01

(100 W)
01BE 01AE −−
02

(200 W)
02BE 02AE − 05DE
04

(400 W)
− 04AE − 05DE
08

(750 W)
− 08AE-S 08AE 10DE
15

(1.5 kW)
− 15AE-S 15AE 15DE
SGMGH
(High Speed Feed)
1500min
-1
10 models
05

(450 W)
−−05AE 05DE
09

(850 W)
−−10AE 10DE
13

(1.3 kW)
−−15AE 15DE
20

(1.8 kW)
−−20AE 20DE
30

(2.9 kW)
−−30AE 30DE
44

(4.4 kW)
−−50AE 50DE
55

(5.5 kW)
−−60AE 60DE
75

(7.5 kW)
−−75AE 75DE
1A

(11.0 kW)
−−1AAE 1ADE
1E

(15.0 kW)
−−1EAE 1EDE
SGMGH
(High Speed Feed)
1000min
-1
8 models
03

(300 W)
−−05AE −
06

(600 W)
−−08AE −
09

(900 W)
−−10AE −
12

(1.2 kW)
−−15AE −
20

(2.0 kW)
−−20AE −
30

(3.0 kW)
−−30AE −
40

(4.0 kW)
−−50AE −
55

(5.5 kW)
−−60AE −
SGMSH
(Super High Power
Capacity)
3000min
-1
6 models
10

(1.0 kW)
−−10AE 10DE
15

(1.5 kW)
−−15AE 15DE
20

(2.0 kW)
−−20AE 20DE
30

(3.0 kW)
−−30AE 30DE
40

(4.0 kW)
−−50AE 50DE
50

(5.0 kW)
−−50AE 50DE
SGMDH
(Flat Type)
2000min
-1
3 models
22

(2.2 kW)
−−30AE −
32

(3.2 kW)
−−50AE −
40

(4.0 kW)
−−50AE −
SGMUH
(High Speed Type)
6000min
-1
4 models
10

(1.0 kW)
−−−10DE
15

(1.5 kW)
−−−15DE
30

(3.0 kW)
−−−30DE
40

(4.0 kW)
−−−50DE
