YASKAWA SGDM Series User Manual

12.3 List of Parameters
12-41
12
* Used only when the software version number is later than 32.
Pn510 Output Signal Selections 3
0000 to 0333 − 0000 After
restart
−
Pn511 Reserved (Do not change)
−−8888 Immedi-
ately
−
Pn512 Output Signal Reversal Settings
−−0000 After
restart
7.3.3
Parameter
No.
Name Setting Range Unit
Factory
Setting
Setting
Validation
Reference
Section
0
1
2
3
Disabled (the above signal is not used.)
Outputs the signal from CN1-25 or -26 terminals.
Outputs the signal from CN1-27 or -28 terminals.
Outputs the signal from CN1-29 or -30 terminals.
Near Signal Mapping (/NEAR)
(Refer to "8.6.6 Positioning Near Signal.")
4th
digit
3rd
digit
2nd
digit
1st
digit
n.
Reserved (Do not change)
Reserved (Do not change)
Same as /NEAR
0 to 3
Reference Pulse Input Multiplication Change Output Signal Mapping (/PSELA)*
(Refer to "10.3.3 Reference Pulse Input Multiplication Range Switching Function.")
0
1
0
1
0
1
Output signal is not reversed.
Output signal is reversed.
Output signal is not reversed.
Output signal is reversed.
Output signal is not reversed.
Output signal is reversed.
Output Signal Reversal for CN1-25 or -26 Terminals
4th
digit
3rd
digit
2nd
digit
1st
digit
n.
Output Signal Reversal for CN1-27 or -28 Terminals
Output Signal Reversal for CN1-29 or -30 Terminals
Reserved (Do not change)
