YASKAWA SGDM Series User Manual

12 Appendix
12-46
* 1. The factory setting is 0001 for the models with 5 kW or more.
* 2. The factory setting is 1500 for the models with 5 kW or more.
Pn40B
2000 Hz
Second Stage Notch Filter Frequency Immediately
Pn40C
70 (0.70)
Second Stage Notch Filter Q Value Immediately
Pn500
7 reference
units
Positioning Completed Width Immediately
Pn501
10 min
-1
Zero Clamp Level Immediately
Pn502
20 min
-1
Rotation Detection Level Immediately
Pn503
10 min
-1
Speed Coincidence Signal Output
Width
Immediately
Pn504
7 reference
units
NEAR Signal Width Immediately
Pn505
1024
reference units
Overflow Level Immediately
Pn506
10 ms
Brake Reference-Servo OFF Delay
Time
Immediately
Pn507
100 min
-1
Brake Reference Output Speed Level Immediately
Pn508
500 ms
Timing for Brake Reference Output
during Motor Operation
Immediately
Pn509
20 ms
Momentary Hold Time Immediately
Pn50A
2100
Input Signal Selections 1 After restart
Pn50B
6543
Input Signal Selections 2 After restart
Pn50C
8888
Input Signal Selections 3 After restart
Pn50D
8888
Input Signal Selections 4 After restart
Pn50E
3211
Output Signal Selections 1 After restart
Pn50F
0000
Output Signal Selections 2 After restart
Pn510
0000
Output Signal Selections 3 After restart
Pn511
8888
Reserved (Do not change) Immediately
Pn512
0000
Output Signal Reversal Settings After restart
Pn513
0088
Input Signal Selections After restart
Pn51A
0
reference units
Position Error Level Between Motor
and Load
Immediately
Pn51B
100
reference units
Reserved (Do not change) Immediately
Pn51C
450 min
-1
Reserved (Do not change) Immediately
Pn51E
0 %
Excessive Position Error Warning
Level
Immediately
Pn600
0 W
Regenerative Resistor Capacity Immediately
Pn601
0 W
Reserved (Do not change) Immediately
Parameter
No.
Factory
Setting
Name
Setting
Validation
