Zebra ZT600 Series User Manual

Routine Maintenance
202
5. While manually rotating the platen roller, clean it thoroughly with the swab. Allow the solvent to
evaporate.
6. Reload the ribbon (if used) and the media. For instructions, see Load the Ribbon onpage47 or Load
the Media onpage17.
7. Rotate the printhead-open lever downward until it locks the printhead in place.

Zebra ZT600 Series Specifications

General

Print Method	Thermal Transfer/Direct Thermal
Print Resolution	203 dpi/8 dots per mm; 300 dpi/12 dots per mm
Maximum Print Width	4.09 in./104 mm
Maximum Print Speed	14 ips (356 mm/s) for 203 dpi, 12 ips (305 mm/s) for 300 dpi
Media Sensors	Reflective and Transmissive
Communication	USB, Serial, Ethernet, Bluetooth
Memory	512 MB Flash
Operating Temperature	5°C to 40°C
