Zebra ZT600 Series User Manual

Diagnostics and Troubleshooting
233
STATUS light steady red
PAUSE light steady yellow
Caution • The cutter blade is sharp. Do not touch or
rub the blade with your fingers.
The cutter blade is in the
media path.
Turn off the printer power and
unplug the printer. Inspect
the cutter module for debris
and clean as needed
following the cleaning
instructions in Clean and
Lubricate the Cutter Module
on page 204.
The USB host port is
disabled, and a USB device
was plugged into the port.
To use the USB device,
select YES, or send the
following SGD command to
the printer:
! U1 setvar
"usb.host.lock_out"
"on"
There is not enough memory
to perform the function
specified on the second line
of the error message.
Free up some of the printer’s
memory by adjusting the
label format or printer
parameters. One way to free
up memory is to adjust the
print width to the actual width
of the label instead of leaving
the print width set to the
default. See PRINT WIDTH
on page 99.
Ensure that the data is not
directed to a device that is
not installed or is unavailable.
If the problem persists, call a
service technician.
Display/
Indicator Lights
Possible Causes Recommended
Solutions
CUT ERROR
USE USB MEMORY
DEVICE?
YES NO
OUT OF MEMORY
STORING GRAPHIC
OUT OF MEMORY
STORING FORMAT
OUT OF MEMORY
STORING BITMAP
OUT OF MEMORY
STORING FONT

Zebra ZT600 Series Specifications

General

Print Method	Thermal Transfer/Direct Thermal
Print Resolution	203 dpi/8 dots per mm; 300 dpi/12 dots per mm
Maximum Print Width	4.09 in./104 mm
Maximum Print Speed	14 ips (356 mm/s) for 203 dpi, 12 ips (305 mm/s) for 300 dpi
Media Sensors	Reflective and Transmissive
Communication	USB, Serial, Ethernet, Bluetooth
Memory	512 MB Flash
Operating Temperature	5°C to 40°C
