Printer Setup and Operation
42
3. Rotate the media guide adjustment knob as shown until the media guide slides all the way out.
4.
Caution • The printhead may be hot and could cause severe burns. Allow the
printhead to cool.
From the media spindle (1), feed the media under the dancer assembly (2), through
the media sensor (3), and under the printhead assembly (4). Slide the media back
until it touches the inside back wall of the media sensor.
