Zebra ZT600 Series User Manual

Printer Setup and Operation
43
5.
6.
Rotate the media guide adjustment knob as shown until the media guide just touches the edge of the
media.
7. Does the media that you are using require ribbon for printing? If you are not sure, see When to Use
Ribbon on page 45.
Caution • The cutter blade is sharp. Do not touch or rub the blade with your fingers.
Feed the media through the cutter.
If using… Then…
Direct Thermal media (no ribbon needed) Continue with step 8.
Thermal Transfer media (ribbon needed)
a. If you have not already done so, load ribbon in
the printer. See Load the Ribbon onpage47.
b. Continue with step 8.

Zebra ZT600 Series Specifications

General

Print Method	Thermal Transfer/Direct Thermal
Print Resolution	203 dpi/8 dots per mm; 300 dpi/12 dots per mm
Maximum Print Width	4.09 in./104 mm
Maximum Print Speed	14 ips (356 mm/s) for 203 dpi, 12 ips (305 mm/s) for 300 dpi
Media Sensors	Reflective and Transmissive
Communication	USB, Serial, Ethernet, Bluetooth
Memory	512 MB Flash
Operating Temperature	5°C to 40°C
