Zebra ZT600 Series User Manual

Printer Setup and Operation
50
6. Is media already loaded in the printer?
If... Then...
No Continue with Load the Media on page 17 to load media in the printer.
Yes
a. Rotate the printhead-open lever downward until it locks the printhead in place.
b. Close the media door.
c. If necessary, press PAUSE to enable printing.

Zebra ZT600 Series Specifications

General

Print Method	Thermal Transfer/Direct Thermal
Print Resolution	203 dpi/8 dots per mm; 300 dpi/12 dots per mm
Maximum Print Width	4.09 in./104 mm
Maximum Print Speed	14 ips (356 mm/s) for 203 dpi, 12 ips (305 mm/s) for 300 dpi
Media Sensors	Reflective and Transmissive
Communication	USB, Serial, Ethernet, Bluetooth
Memory	512 MB Flash
Operating Temperature	5°C to 40°C
