5-8 CELL-DYN 3000 System Operator’s Manual
9140240E — May 1995
Operating Instructions Chapter 5
Figure 5.4: Patient Limits Screen
The [PATIENT LIMITS] key is used to enter upper and lower flagging
limits for groups of patient samples. (For example, limits may be entered
for adult males, adult females, neonates, etc.)
CAUTION: When entering the limits into the four (4) Patient
Limits Sets, ensure that the upper and lower limits for each
parameter do not exceed the linearity claims. (Refer to the
linearity specifications in Chapter4, System Specifications.)
This will ensure that any value that exceeds these limits will be
flagged for further review.
The following soft key labels are displayed (see Figure 5.4) when the
[PATIENT LIMITS] key is pressed:
LIMIT SET 1
LIMIT SET 2
LIMIT SET 3
LIMIT SET 4
PRINT
RETURN
LIMIT
SET 2
LIMIT
SET 3
LIMIT
SET 4
PRINT RETURN
LIMIT SET 1
Ready
Jun 30 1992
Operator ID
Sequence #
11:15
734
6799
WBC:
NEU:
LYM:
MONO:
EOS:
BASO:
RBC:
HGB:
HCT:
MCV:
MCH:
MCHC:
RDW:
PLT:
MPV:
PCT:
PDW:
Upper Limits
4.6
2.0
0.6
0.0
0.0
0.0
4.04
12.2
37.7
80.0
27.0
31.8
11.6
142
0.0
0.00
0.0
K/uL
K/uL
K/uL
K/uL
K/uL
K/uL
M/uL
g/dL
%
fL
pg
g/dL
%
K/uL
fL
%
10(GSD)
37.0
10.0
0.0
0.0
0.0
%N
%L
%M
%E
%B
10.2
6.9
3.4
0.9
0.7
0.2
6.13
18.1
53.7
97.0
31.2
35.4
14.8
424.
99.9
9.99
99.9
K/uL
K/uL
K/uL
K/uL
K/uL
K/uL
M/uL
g/dL
%
fL
pg
g/dL
%
K/uL
fL
%
10(GSD)
80.0
50.0
12.0
7.0
2.5
%N
%L
%M
%E
%B
