5-38 CELL-DYN 3000 System Operator’s Manual
9140240E — May 1995
Operating Instructions Chapter 5
PARAM SET 2*
PARAM SET 3*
PARAM SET 4*
CUSTOMIZE PRINTOUT
CUSTOMIZE HEADER
or
CANCEL GRAPH (This key label alternates
between these two selections
when [SELECT GRAPH] is
pressed.)
SELECT GRAPH or
PLACE GRAPH or
TOGGLE PARAMETER (The key label alternates among
these three selections when the
soft key is pressed.)
SETUP
* The soft key for the displayed parameter set is not displayed.
Using the [PARAM SET "X"] key, the display may be customized for
four different sets of parameters. Up to 20 individual parameters and up
to four scatterplots and/or histograms may be displayed in each set. (An
“empty” selection may be used to “blank” the scatterplot or histogram
display at the selected position.) The screen is divided into two sections.
Individual parameters are listed in the left section and the scatterplots
and histograms are listed in the right section.
Procedure Customize Display
1.From the SETUP MENU Screen, press [CUSTOMIZE
REPORT] and if necessary, press [CUSTOMIZE DISPLAY] to
display a parameter set.
2.If desired, press [PARAM SET "X"] to select a different
parameter set.
3.Use the Arrow keys on the keyboard to move the cursor to the
desired parameter in the list displayed on the left section of the
screen.
4.Press [TOGGLE PARAMETER] to turn the display OFF or ON
and advance the cursor to the next parameter. The cursor moves
through the entire list of parameters in this section of the screen
and, when at the bottom, returns to the top of this list.
