CELL-DYN 3000 System Operator’s Manual 11-5
9140240E — May 1995
Chapter 11 Printer
Maintenance
Every six months (or after 300 hours of operation), use a clean, dry cloth
to dust the area around the carriage shaft and platen. Be sure to remove
any loose particles of paper. Do not use solvents or strong detergents on
the cabinet.
WARNING: Be sure to turn the printer OFF and disconnect the
power cord before cleaning.
Figure 11.2: Printer Carriage Shaft and Platen
Platen
Carriage Shaft
To Next Page
