1-18 CELL-DYN 3000 System Operator’s Manual
9140240E — May 1995
System Description Chapter 1
Front Panel
Video Display Screen
A 14-inch diagonal, high-resolution video display screen with 16-color
illumination displays all alphanumeric and graphic data.
Soft Keys
A row of eight unlabeled pressure-sensitive soft keys is located directly
below the screen. Each key generates an audible tone when pressed and
initiates a function defined by the screen label currently displayed
directly above it.
Primary Keys
The pressure-sensitive primary keys are located directly below the soft
keys. Each key generates an audible tone when pressed. These keys
consist of the following numeric and special function keys:
• Numeric keys — a block of ten numeric keys, labeled from 0 to 9
and a decimal key which are used to enter numeric data
• ENTER key — stores entered numeric data and advances the
cursor to the next entry location
• ESC key — allows the operator to escape (abort) data entry before
it is completed
• Arrow keys — a set of four keys used to move the cursor in the
direction depicted by each arrow
• Page Up key — used to display the previous screen of data that is
stored in a log format, eliminating the need to scroll through data
lines one by one
• Page Down key — used to display the next screen of data that is
stored in a log format, eliminating the need to scroll through data
lines one by one
• HELP key — not currently supported
Data Station Keyboard
The Data Station keyboard contains a complete set of pressure-sensitive
alphabetic keys. It also contains a Backspace key, an Escape key, an
Enter key, a Comma key and a Space key. The keyboard folds up when it
is not in use.
