CELL-DYN 3000 System Operator’s Manual 10-31
9140240E — May 1995
Chapter 10 Troubleshooting
Figure 10.21: Open Sample Aspiration Probe
2. Carefully insert the monofilament line into the probe and push it
down through the probe until it extends from the end. If a clot has
been pushed out of the probe, remove it from the monofilament
line.
3. Remove the monofilament line from the probe.
4. Reconnect the tubing to the top of the probe.
5. Perform an Auto-Clean procedure. (If necessary, refer to the
directions given in Chapter 9, Maintenance.)
6. When the Auto-Clean procedure is complete, run a blood sample
and check for complete aspiration. (There should be a minimum of
one inch of blood on either side of the shear valve tubing.)
7. If aspiration is not complete, call for technical assistance.
Sample
Aspiration
Probe
Wash Block
Locking Bracket
Silicon Tubing
Sleeve
Disconnect At
This Point
Open
