2-8 CELL-DYN 3000 System Operator’s Manual
9140240E — May 1995
Installation Chapter 2
Sample Loader
Installation
A metal pedestal is shipped with the CELL-DYN 3000SL. This pedestal
has an attached platform for the Sample Loader. The pedestal is placed
under the Analyzer and the Sample Loader is set on the platform.
Figure 2.2: Analyzer with Sample Loader
Mechanical and Electrical Setup
1. Unpack the Sample Loader from its shipping container. Place it on
the platform as shown in Figure 2.2.
2. Remove the protective plastic and inspect the module for damage.
Analyzer
Data Station
Analyzer Pedestal
Sample Loader Platform
Sample Loader
