5-54 CELL-DYN 3000 System Operator’s Manual
9140240E — May 1995
Operating Instructions Chapter 5
Status Box
The Status Box is displayed in the Top Center of the Data Station RUN
Screen. It contains the following information:
•Menu in use
•The Status of the Analyzer — the READY, NOT READY and
FAULT messages are displayed here
•Report or File identity for results currently displayed
The Top Right Corner of the Data Station RUN Screen displays the
following information:
•Current date and time
•Operator ID — Identification of the current operator
•Sequence # — Automatically incremented as samples are run
•Selected Sampler mode — Open Sampler or Closed Sampler
The Center Section of the Data Station RUN Screen displays the results.
A list of the parameters and results is displayed on the left side.
Scatterplots and histograms are displayed on the right side. The area
between the parameter data and the graphic data is used to display
flagging messages. Examples of the count times and some of the
flagging messages are shown in Figure 5.25.
A detailed explanation of all flagging messages is given in Chapter3,
Principles of Operation.
