5-20 CELL-DYN 3000 System Operator’s Manual
9140240E — May 1995
Operating Instructions Chapter 5
The feature enabling the transfer of QC limits and data into a QC file
from a floppy disk is not currently available. Therefore the following
keys mentioned in this manual should not be used at this time: [LAB ID
SETUP], [LOAD FROM DISK], and [WRITE QC TO DISK].
The [SETUP QC FILE] key is used to configure the QC file. If the file
is used for a commercial control, the lot number and expiration date may
be entered by pressing the [LOT NUMBER] key. If the file is used for a
patient control, the ID number of the control may be entered by pressing
the [REPLICATE ID] key. This screen is also used to select the
Westgard Rules that will be applied to the QC data stored in the file. The
following soft key labels are displayed when the [SETUP QC FILE]
key is pressed:
REPLICATE ID or
LOT NUMBER (The key label alternates between
these two selections.)
TOGGLE ON/OFF (This key label is present only when
the cursor is in one of the Westgard
Rule Selection fields.)
PRINT
RETURN
The LOT NUMBER ENTRY and REPLICATE ID ENTRY Screens
are shown in the procedures which follow. The numbers on the QC
FILE SET UP Screens shown in Figure5.10 and Figure 5.11
correspond to the following numbered options:
1.<REPLICATE ID> entry field (see the following figure)
This entry field is displayed when the [REPLICATE ID] key is
pressed. This designation is intended for QC Files that are used for
patient controls.
LOAD
FROM DISK
SETUP
QC FILE
