5-28 CELL-DYN 3000 System Operator’s Manual
9140240E — May 1995
Operating Instructions Chapter 5
Figure 5.14: Customize QC Printout Screen
The [CUSTOMIZE PRINTOUT] key is used to customize the printout
format for the QC logs. (See Figure 5.14.) The following soft key labels
are displayed when the [CUSTOMIZE PRINTOUT] key is pressed:
SELECT PARAMETER
STANDARD SELECTION
RETURN
The CUSTOMIZE QC PRINTOUT Screen displays the group of
parameters that is currently selected. A list of all available parameters is
displayed under the group. The following parameters are included in the
list and may be printed in the QC Log if desired:
UMT1 and UMT2 — UMT1 is the RBC/PLT Upper Metering
Time. UMT2 is the RBC/PLT Upper
Metering Time for an extended count.
SELECT
PARAMETER
STANDARD
SELECTION
RETURN
CUSTOMIZE QC PRINTOUT
Ready
Dec 17 1992
Operator ID
Sequence #
16:49
734
0630
FOR Normal
WBC%N%L%M%E%BRBCHGBHCTMCVMCHMCHC
RDWPLTMPVUMT1CNT1
WBC NEU LYM MONO EOS BASO
RBC HGB HCT MCV MCH MCHC RDW
PLT MPV PCT PDW
%N %L %M %E %B
UMT1 UMT2 CNT1 CNT2
CUSTOMIZE
PRINTOUT
