10-18 CELL-DYN 3000 System Operator’s Manual
9140240E — May 1995
Troubleshooting Chapter 10
When the [VOLTAGE READINGS] key is pressed, the voltage and
vacuum/pressure values from a test point, measured at the moment when
the key was pressed, is displayed. (See Figure 10.15.) The following
additional soft key labels are displayed:
FINISH SELECT
SELECT
These two keys are for service use only.
The data provided by the VOLTAGE READINGS Screen can be useful
in determining if a problem is caused by a hardware malfunction.
Figure 10.15: Voltage Readings Screen
VOLTAGE
READINGS
FINISH
SELECT
SELECT DIGITAL
READINGS
VOLTAGE
READINGS
MORE PRINT MAIN
DIAGNOSTICS MENU
Ready
Jan 28 1993
Operator ID
Sequence #
12:40
734
3143
Arrow keys to move around, SELECT key to select, FINISH SELECT key to go
DCM:
slf-tst f/ DAC :0.00 99mv refrence :0.08 15v/2 pwr sp :7.49 5v pwr sp :5.14
slf-test ramp :9.99 9.901v refrnce :9.86 -15v/2 pwr sp :-7.55
SPM:
WBC threshold :0.86 SPM tst f/ DAC :0.00 WBC ch 1 peak :0.00 RBC peak :0.00
RBC threshold :0.57 5v supply :5.12 WBC ch 2 peak :0.00 RBC intgral :0.00
PLT L thrshld :0.53 10v refrence :9.97 WBC ch 3 peak :0.00 PLT peak :0.04
PLT H thrshld :9.97 -10v refrence :-10.0 WBC ch 4 peak :0.00
MAM:
ch 1 offset :0.20 ch 5 offset :-2.06 electrode v/2 :0.41 laser ref :0.00
ch 2 offset :0.97 ch 6 offset :-3.00 apt crrnt set :-0.05
ch 3 offset :0.64 ch 3-Vdyn/100 :6.14 tst puls H set :-0.05
ch 4 offset :0.27 ch 4-Vdyn/100 :5.65 tst puls L set :-0.00
VPM:
press 1 psi :12.0 press 3 psi :4.88 vac 1 in. Hg :11.8 pos ref pres :5.00
press 2 psi :9.01 vac 2 in. Hg :11.7 neg ref pres :-5.07
FCM:
HGB output :5.53
