Abov MC97F60128 - Page 134

134
MC97F60128
ABOV Semiconductor Co., Ltd.
IP2L (Interrupt Priority 2 Low Register): 9CH
7
6
5
4
3
2
1
0
–
–
IP2L5
IP2L4
IP2L3
IP2L2
IP2L1
IP2L0
–
–
R/W
R/W
R/W
R/W
R/W
R/W
Initial value :00H
IP2H (Interrupt Priority 2 High Register): 9DH
7
6
5
4
3
2
1
0
–
–
IP2H5
IP2H4
IP2H3
IP2H2
IP2H1
IP2H0
–
–
R/W
R/W
R/W
R/W
R/W
R/W
Initial value :00H
IP2L[5:0],
IP2H[5:0]
Select IE Interrupt Priority
IP2Hx
IP2Lx
Description
0
0
level 0 (lowest)
0
1
level 1
1
0
level 2
1
1
level 3 (highest)
IP3L (Interrupt Priority 3 Low Register): 9EH
7
6
5
4
3
2
1
0
–
–
IP3L5
IP3L4
IP3L3
IP3L2
IP3L1
IP3L0
–
–
R/W
R/W
R/W
R/W
R/W
R/W
Initial value :00H
IP3H (Interrupt Priority 3 High Register): 9FH
7
6
5
4
3
2
1
0
–
–
IP3H5
IP3H4
IP3H3
IP3H2
IP3H1
IP3H0
–
–
R/W
R/W
R/W
R/W
R/W
R/W
Initial value :00H
IP3L[5:0],
IP3H[5:0]
Select IE3 Interrupt Priority
IP3Hx
IP3Lx
Description
0
0
level 0 (lowest)
0
1
level 1
1
0
level 2
1
1
level 3 (highest)
