Abov MC97F60128 User Manual

137
MC97F60128
ABOV Semiconductor Co., Ltd.
EIFLAG2 (External Interrupt Flag 2 Register): BCH
7
6
5
4
3
2
1
0
FLAG17
FLAG16
FLAG15
FLAG14
FLAG13
FLAG12
FLAG11
FLAG10
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value :00H
EIFLAG2[7:0]
When an External Interrupt 10-17 is occurred, the flag becomes ‘1’.The flag is cleared
only by writing ‘0’ to the bit. So, the flag should be cleared by software. Writing “1”
has no effect.
0
External Interrupt 10 ~ 17 not occurred
1
External Interrupt 10 ~ 17 occurred
EIPOL2H (External Interrupt Polarity 2 High Register): C5H
7
6
5
4
3
2
1
0
POL17
POL16
POL15
POL14
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value: 00H
EIPOL2H[7:0]
External interrupt (EINT17, EINT16, EINT15, EINT14) polarity selection
POLn[1:0]
Description
0
0
No interrupt at any edge
0
1
Interrupt on rising edge
1
0
Interrupt on falling edge
1
1
Interrupt on both of rising and falling edge
Where n =14, 15, 16 and 17
EIPOL2L (External Interrupt Polarity 2 Low Register): C4H
7
6
5
4
3
2
1
0
POL13
POL12
POL11
POL10
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value: 00H
EIPOL2L[7:0]
External interrupt (EINT10, EINT11, EINT12, EINT13) polarity selection
POLn[1:0]
Description
0
0
No interrupt at any edge
0
1
Interrupt on rising edge
1
0
Interrupt on falling edge
1
1
Interrupt on both of rising and falling edge
Where n =10, 11, 12 and 13
